Item
Insulation Resistance
Specification
The initial minimum is 1000 MΩ. The minimum is 500 MΩ after the test.
Condition
AC500 V ±10V, Power on adjacent pins for 1 minute.
Item
Withstand Voltage
Specification
No short circuit, attenuation, spark or other defects. spark or other defects.
Condition
AC500 V. Power on for 1 minute, lower than 1 mA leakage current
Item
Contact Resistance
Specification
Initial 50mΩ max. The impedance change after the test is less than 30mΩ.
Condition
It was measured at 100 mA current and 20mV voltage.
Item
Normal Force of Terminal
Specification
50gf min/PIN50gf min/PIN50gf min/PIN50gf min/PIN
Condition
Press down to 0.10mm from the plastic surface.
Item
Lifetime
Specification
No visible damage, the normal force to meet specifications. meet.
Condition
2000 times; Speed: 10 times/min.
